Instant water heater Kospel EPS2-4,4.P, with shower

Instant water heater Kospel KDE5, 9-24kW, 3 phase, LCD display

Delivery time: 7-10 business days
Delivery cost: 0€

KDE5 electronic LCD
An electric flow-through water heater with electronic controls and a clear LCD display. KDE5 is a 3-phase model that supplies water to several water consumption points such as the kitchen and the bathroom. The heater is available with a power range from 9kW to 27kW, which allows for the perfect selection of the device to the individual needs of the user.

In a nutshell:

• multi-point heater
• wide power range from 9kW to 27kW/400V
• LCD display
• electronic control

Electronic control system
- stability and smooth regulation of water temperature
- the possibility to regulate water temperature from 30OC to 60OC (1OC step)

4 powers in 1 heater
- allows the user to select desired power level (not applicable for 27kW)

The possibility to re-heat already pre-heated water
- the temperature output until 60OC

Reheating pre-heated water allows the heater to interact with other devices
The inlet water temperature can be up to 60°C. This solution allows the heater to interact with another heat source and preheat water with the use of, for example, a solid fuel boiler in cooperation with a hot water tank.

Temperature lock
- allows the user to save the maximum temperaturę
- it protects children against burn injuries

Temperature memory
- allows the user to save three most frequently used water temperatures



Water heater KDE5      9-11-12-15 kW	Water heater KDE5         17-18-21-24 kW
9 kW – 4.3 l / min	17 kW – 8.1 l / min
11 kW – 5.2 l / min	18 kW – 8.7 l / min
12 kW – 5.8 l / min	21 kW – 10.1 l / min
15 kW – 7.2 l / min	24 kW – 11.6 l / min

Tekniset tiedot

KDE5 9-11-12-15 kW

Tyyppi	KDE5 Electronic LCD
Rated power	9 kW/11 kW/12 kW/15 kW
Rated Voltage	400V 3N~
Rated current	3 × 13A/15.9A/17.3A/21.7A
Size of fuse	3 × 16A/16A/20A/25A
water pressure MPa min/max	1.0-10 bar
Water fittings	G 1/2” (distance between inlet and outlet 100 mm)
Size (LxHxD)	245 x 440 x 126 mm
Weight	4.0 kg
Protection rating	IP25 tai IP65

KDE5 17-18-21-24 kW

Tyyppi	KDE5 Electronic LCD
Rated power	17 kW/18 kW/21 kW/24 kW
Rated voltage	400V 3N~
Rated current	3 × 25.8A/26A/30.3A/34.6A
size of fuse	3 × 25A/30A/35A/35A
Water pressure MPa min/max	1.0-10 bar
Water fittings	G 1/2” (distance between inlet and outlet 100 mm)
Size (LxHxD)	245 x 440 x 126 mm
Weight	4.0 kg
protection rating	IP25 tai IP65
