Instant water heater Kospel PPE4, 10-24kW, 3 phase, LCD display
Price:
299,00
€
29900
583,65 €
58365
Qty: pcs
Files
Kospel instant water heater PPE4, 10-15 and 17-24kW, 3 phase, LCD display
Toimituskulut: 9,90 €
Toimitusaika: 7-10 business days
Instant water heater Kospel PPE4.M, 10-15 and 17-24kW, 3 phase, LCD display
An electric flow-through water heater with electronic controls and a clear LCD display. PPE4 is a 3-phase model that supplies water to several water consumption points such as the kitchen and the bathroom. The heater is available with a power range from 9kW to 27kW, which allows for the perfect selection of the device to the individual needs of the user.
In a nutshell:
Electronic Control
Precise and comfortable water temperature regulation in the range of 30-60 °C with an accuracy of 1 °C.
4 Power Levels in One Water Heater
Option to select maximum power (not applicable to 27 kW).
Remote Access Application
Control and monitoring of the water heater's operating parameters.
Possibility to Reheat Preheated Water
Water temperature at the inlet up to 60 °C.
LCD Display
Energy and water consumption statistics
Indication of inlet and outlet water temperature
Flow rate indication
Indication of the currently activated device power
Limitation of maximum temperature setting - protection against burns
Memory for the 3 most commonly used temperature settings
Toimitusaika: 7-10 business days
Instant water heater Kospel PPE4.M, 10-15 and 17-24kW, 3 phase, LCD display
An electric flow-through water heater with electronic controls and a clear LCD display. PPE4 is a 3-phase model that supplies water to several water consumption points such as the kitchen and the bathroom. The heater is available with a power range from 9kW to 27kW, which allows for the perfect selection of the device to the individual needs of the user.
In a nutshell:
- LCD display
- electronic control
Electronic Control
Precise and comfortable water temperature regulation in the range of 30-60 °C with an accuracy of 1 °C.
4 Power Levels in One Water Heater
Option to select maximum power (not applicable to 27 kW).
Remote Access Application
Control and monitoring of the water heater's operating parameters.
Possibility to Reheat Preheated Water
Water temperature at the inlet up to 60 °C.
LCD Display
Energy and water consumption statistics
Indication of inlet and outlet water temperature
Flow rate indication
Indication of the currently activated device power
Limitation of maximum temperature setting - protection against burns
Memory for the 3 most commonly used temperature settings
| Water heater 10-11-12-15 kW | Water heater 17-18-21-24 kW |
|---|---|
| 10 kW – 4.3 l / min | 17 kW – 8.1 l / min |
| 11 kW – 5.2 l / min | 18 kW – 8.7 l / min |
| 12 kW – 5.8 l / min | 21 kW – 10.1 l / min |
| 15 kW – 7.2 l / min | 24 kW – 11.6 l / min |
Tekniset tiedot
PPE4 10-11-12-15 kW
| Tyyppi | PPE4.M Electronic LCD |
|---|---|
| Rated power | 10/11/12/15 kW |
| Rated Voltage | 400V 3N~ |
| Rated current | 3 × 13A/15.9A/17.3A/21.7A |
| Size of fuse | 3 × 16A/16A/20A/25A |
| water pressure MPa min/max | 1.0-10 bar |
| Water fittings | G 1/2” (distance between inlet and outlet 100 mm) |
| Size (LxHxD) | 245 x 440 x 126 mm |
| Weight | 4.0 kg |
| Protection rating | IP25 tai IP65 |
PPE4 17-18-21-24 kW
| Tyyppi | PPE4.M Electronic LCD |
|---|---|
| Rated power | 17 kW/18 kW/21 kW/24 kW |
| Rated voltage | 400V 3N~ |
| Rated current | 3 × 25.8A/26A/30.3A/34.6A |
| size of fuse | 3 × 25A/30A/35A/35A |
| Water pressure MPa min/max | 1.0-10 bar |
| Water fittings | G 1/2” (distance between inlet and outlet 100 mm) |
| Size (LxHxD) | 245 x 440 x 126 mm |
| Weight | 4.0 kg |
| protection rating | IP25 tai IP65 |
